Ortofon Concorde MkII CLUB DJ Cartridge

The CLUB boasts the best specifications and best sound, making it an ideal choice for Club DJs in any environment: studio, broadcast or club.
• The CLUB features a Special-Elliptic stylus that allows for detailed sound quality: Special-Elliptic stylus fits better in the groove and therefore has more contact area with the groove itself, extracting more intricate details, than is possible with a spherical diamond.
• The CLUB’s 8 mV output voltage requires less gain from the preamps, providing cleaner sound reproduction and less susceptibility to feedback in live environments.

Concorde MKII Technical data

• Output voltage at 1000Hz, 5cm/sec. – 8 mV
• Channel balance at 1kHz – 1 dB
• Channel separation at 1kHz – 25 dB
• Channel separation at 15 kHz – 15 dB
• Frequency range at -3dB – 20-20.000 Hz
• Tracking ability at 315 Hz at recommmended tracking force – 100 μm
• Compliance, dynamic lateral – 14 μm/m N
• Stylus type – Special Elliptical r/R 13/25 μm
• Tracking force range – 2 – 4 g
• Tracking force recommended – 3 g
• Cartridge weight – 18,5 g
• Internal impedance, DC resistance – 1.2 kOhm
• Internal inductance – 630 mH
• Recommended load resistance – 47 kOhm
• Recommended load capacitance – 150-300 pF
• Cartridge colour, body/stylus – Black/Bronze
• Cartridge weight – 7.2 g
