THE PERFECT ADD ON
The PSU-1250 features a 7-Transformer design, with 4 transformers dedicated exclusively to the power supply stage, of which one for the galvanic insulation of the audio stage, and 3 dedicated to the Dual Choke Inductive Filter.
ULTRA CLEAN POWER
Our external power supplies perfectly filter the AC current and remove interference and electrical noise from the power system, allowing our electronics to perform at their best. Most importantly, they ensure the electronics always receive the optimal amount of power without generating EMI (ElectroMagnetic Interference) nor RFI (Radio-Frequency Interference) that could affect the audio signal.
Specifications:
- PSU-1250: 7 low-noise voltage regulators
- Maximum variation of output voltage: 0,05%
- Line noise rejection: >80dB
- Common mode noise rejection: >80dB
- Absolute phase control selectable from front panel
- Power supply 100-120V / 220-240V with auto sense, 50/60Hz
- Power consumption: 100W
- PSU-1250 Dynamic power: >300W
- Stand by power: <1W
- Full Power Response Time: < 2,5µsec
- Fuse: 3,15A F/T
- Dimensions: 425 W x 135 H x 360 D mm
- PSU-1250 Weight: Kg. 21 net
