Specifications:
- Drivers: HF ATC 25mm dual suspension Tweeter, Mid 75mm ATC Soft Dome, LF ATC 164mm SC
- Matched Response: ±0.5dB
- Frequency Response (-6dB): 48Hz-22kHz
- Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
- Max SPL: 112dB
- Crossover Frequencies: 380Hz & 3.5kHz
- Input Connector: Female XLR
- Input sensitivity : 1V
- Filters : 4th Order critically damped with phase compensation.
- Overload Protection : Active FET momentary gain reduction.
- Fault Protection : DC fault protection and thermal trip. Fault indication on rear panel mounted LED.
- Amplifier Output: 150W LF, 60W MF, 32W HF
- Cabinet Dimensions (HxWxD): 980 x 370 x 344mm / 38.58 x 14.56 x 13.54″ (inc. foot plinth & amp, spikes add 25mm to height, grill adds 34mm to depth)
- Weight: 36kg
- Spikes: 4 per cabinet, M8 x 1.25mm
